8.8kW/11kVA, 230v, water-cooled 1500rpm, ComAp MRS10 Control Panel

£5,999.99 inc. VAT (£4,999.99 ex. VAT)

8.8kW/11kVA, 230v, water-cooled 1500rpm, ComAp MRS10 Control Panel

£5,999.99 inc. VAT (£4,999.99 ex. VAT)

Key Features
  • Single-phase diesel generator: Produces up to 11kVA of backup power and 10KVA prime power
  • Powered by a 1500rpm engine: Extends the lifespan of the generator
  • Fitted with an AVR alternator: Able to produce a clean energy output
  • Silenced generator: Housed in a weather-proof canopy, producing only 65dB at 7m
  • ATS compatible: Automatically transfers power to the generator in the event of a power cut
  • Peace of mind: Up to 2 year Hyundai warranty* (terms apply)

Product Description

Hyundai 8.8kW/11kVA Single Phase Diesel Generator

8.8kW Single-Phase Diesel Generator

The DHY9KSEm is a powerful single-phase diesel generator from Hyundai. Suitable for providing your home or business with either prime power, if you just have a few appliances to run, or for backup power when the national grid lets you down.

Powered by an 11hp HY380 diesel engine, the DHY9KSEm is able to produce a maximum output of 11KVA / 8.8kW backup power and 10KVA / 8kW prime power.

ATS Compatible Hyundai Generator

The DHY9KSEm can be started manually by using the key, or connected to an ATS (Automatic Transfer Switch) system, which will automatically turn on the generator when a loss of power to the property is detected. When power returns from the mains, the ATS module will then safely turn your generator off.

This is ideal for those who need to guarantee constant power – for example, if you run servers or have refrigeration units.

Silenced Generator

Housed in a weather-proof ‘silenced’ canopy, the DHY9KSEm produces only 65dB @ 7 metres which makes it a quiet standby generator which won’t interrupt you at home or work.

Diesel generators are ideal for backup applications as sometimes petrol can go stale and prevent a generator working. Our diesel generators also run happily on budget-friendly red diesel, without voiding the warranty and making it cost-effective to refuel.

1500rpm Generator

1500rpm diesel generators are ideal for static installation for daily prime power, as well as for regular standby generator/backup generator use.

1500rpm generators have slower running, water-cooled engines which are less stressed than 3000rpm generators, which make them the best option if you’re going to use your generator as your main power source and will also prolong its lifespan.

Equipped with an AVR alternator to produce clean energy, the DHY9KSEm is suitable for powering sensitive electronic equipment, such as televisions, PCs and laptops, in your home or business.

Delivery

Kerbside delivery is included in the price. However, please note that a forklift will be required for unloading.

2 Year Warranty

This 11kVA diesel generator comes with a 1 year / 1,000 hour warranty which can extended to 2 years* (subject to standby use of 500 hours per year – terms apply) with full UK parts and service backup for added peace of mind. Read our warranty terms here.

Generator kVA Ratings

All of our single-phase generators have a kVA rating that is higher than the kW. This is because we have assumed the appliances you are going to power have a load factor/power factor of 0.8 – therefore the ‘assumed’ kVA rating of the load would be higher. This is industry standard and it is usually best to scope the right unit based on the kW.

Specifications

ModelDHY9KSEm
Rated/Prime kVA*10
Rated/Prime kW8
Max/Standby kVA*11.25
Max/Standby kW9
PhaseSingle
Voltage230
Connection Method(s)1 x 230V/32A 1 x 230V/63A
Rated Speed (RPM)1500
Frequency (Hz)50
Max/Continuous Current (Amps)39 / 34.8
Power Factor (Cosφ)1
Fuel TypeDiesel
Fuel Tank (Litres)42
Runtime (Hours) @ 100% Load12
Noise Level @ 1m 75% load (dB)68
Noise Level @ 7m 75% load (dB)62
Hyundai Diesel Engine ModelHY380
Power Output (kw)11
Displacement (CC)1.36
No. of Cylinders3
Displacement (Litres)1.4
Recommended Oil TypeSAE 15W40
Oil Capacity (Litres)1.36
Oil Filter Part No.JX0810Y
AspirationNatural
Fuel Regulation/Governor SystemMechanical
Fuel Consumption (100% Load) [Litres]3.5
Fuel Filter Part No.C0506
CoolingWater
Alternator Model164B
Breakers2P C40A 100mA
Alternator TypeBrushless
Voltage RegulationAVR
Air Filter Part No.K1317
Net Weight (kg)480
Gross Weight (kg)480
Dimensions L x W x H (mm)1500x 760 x 1090
Battery System / Starting (V – Ah)2×12/30
ATS / MTS CompatibleYes
Control PanelComAp MRS10
Model EAN700621496199
Warranty1 Year / 1000 Hours (can extended to 2 years, subject to standby use of 500 hours per year. Terms apply*)
Product TypeDiesel Generator

For Bulk orders please call the AMIA Head office on 01363 82928 to get an accurate shipping price. To keep up to date with AMIA go to our Facebook page www.facebook.com/amiamachinery

For more information on all of the ranges of machinery which AMIA exclusively distribute in the UK and Ireland please go to www.agrimarketia.com. Please email the AMIA Headoffice at office@agrimarketia.com.

Browse the different machinery available from AMIA on our AMIA Online Shop including Agricultural Machinery, Construction Machinery, Garden Machinery, Woodchippers, Log Splitters, Power Barrows, Walk behind Trenchers, Rollers, Chain Harrows etc here – https://shop.agrimarketia.com/product-category/products/machinery/

Product Specification

Model

DHY9KSEm

Rated/Prime kVA*

10

Rated/Prime kW

8

Max/Standby kVA*

11.25

Max/Standby kW

9

Phase

Single

Voltage

230

Connection Method(s)

1 x 230V/32A 1 x 230V/63A

Rated Speed (RPM)

1500

Frequency (Hz)

50

Max/Continuous Current (Amps)

39 / 34.8

Power Factor (Cosφ)

1

Fuel/Power Source

Diesel

Fuel Tank (Litres)

42

Runtime (Hours) @ 100% Load

12

Noise Level @ 1m 75% load (dB)

68

Noise Level @ 7m 75% load (dB)

62

Hyundai Diesel Engine Model

HY380

Power Output (kw)

11

Displacement (CC)

1360

No. of Cylinders

3

Displacement (Litres)

1.36

Oil Capacity (Litres)

3.5

Oil Filter Part No.

JX0810Y

Aspiration

Natural

Fuel Regulation/Governor System

Mechanical

Fuel Consumption (100% Load) [Litres]

3.5

Fuel Filter Part No.

C0506

Cooling

Water

Alternator Model

164B

Breakers

2P C40A 100mA

Alternator Type

Brushless

Voltage Regulation

AVR

Air Filter Part No.

K1317

Net Weight (kg)

480

Gross Weight (kg)

480

Dimensions L x W x H (mm)

1500x 760 x 1090

Battery System / Starting (V - Ah)

2×12/30

ATS / MTS Compatible

Yes

Control Panel

ComAp AMF9

Model EAN

700621496199

Warranty

1 Year / 1000 Hours (can extended to 2 years, subject to standby use of 500 hours per year. Terms apply*)

Product Type

Diesel Generator

Assembly Required?

Yes – some assembly may be required
