OXDALE PRODUCTS PTO400 Big Base Log Splitter

Name: OXDALE PRODUCTS PTO400 Big Base Log Splitter
SKU: 10832
Price: 1475.00 GBP
Availability: InStock

Original price was: £1,824.00.Current price is: £1,770.00. inc. VAT (£1,475.00 ex. VAT)

OXDALE PRODUCTS PTO400 Big Base Log Splitter

Original price was: £1,824.00.Current price is: £1,770.00. inc. VAT (£1,475.00 ex. VAT)

Categories: Agricultural Machinery, Amenity, Compact Tractor Machinery, Forestry Machinery, Oxdale Products

OXDALE PTO400 Big Base Log Splitter

The Oxdale PTO400 Big Base Log Splitter offers powerful and versatile log splitting for most tractors, including those with low horsepower and limited hydraulic systems. Featuring a robust 10-ton splitting force and a specially forged axe head with a double chamfer, it efficiently handles logs up to 18 inches high. This splitter mounts easily on standard rear three-point linkages and can be positioned at the front or rear of the tractor. Built for safety and ease of use, it includes anti-burst lagging on hydraulic pipes and requires both hands to operate.

Product Description

OXDALE PTO400 Big Base Log Splitter

The Oxdale PTO400 Big Base Log Splitter is a durable and efficient solution for a wide range of tractors, making it an ideal choice for those lacking built-in hydraulic systems or having lower horsepower. Designed to fit standard rear three-point linkage tractors, this log splitter is perfect for tractors with low hydraulic capabilities, ensuring efficient operation even in challenging conditions.

Key Features:

PTO Driven: Utilizes the tractor’s PTO for power, making it compatible with various tractors.
10-Ton Splitting Force: Delivers impressive force for effective log splitting.
Forged Axe Head: The specially designed axe head is forged, hardened, and features a double chamfer for superior splitting action.
Versatile Mounting: Can be attached to either the front or rear three-point linkage of ISO cat 1 and cat 2 tractors, accommodating both compact and high-horsepower models.
Safety Features: Hydraulic pipes are covered with anti-burst lagging, and operation requires both hands on the handles to ensure safe use.
Log Capacity: Capable of splitting logs up to 18 inches high, with no limitation on log width.

Contact Us

For bulk orders or to inquire about shipping costs, please call the AMIA Head Office at 01363 82928. Stay updated with the latest from AMIA by visiting our Facebook page: AMIA Machinery.

To explore the full range of machinery exclusively distributed by AMIA in the UK and Ireland, visit our website: Agrimarketia. For more information or inquiries, please email the AMIA Head Office at office@agrimarketia.com.

Browse our extensive selection of machinery on the AMIA Online Shop, including agricultural machinery, construction machinery, garden equipment, woodchippers, log splitters, power barrows, walk-behind trenchers, rollers, chain harrows, and more: AMIA Online Shop.

Product Specification

Model	Oxdale PTO400 Big Base
Minimum Horsepower	10 HP
Weight	85 kg
Linkage Compatibility	ISO CAT 1/2
Maximum Operating Pressure	3625 psi / 250 bar
Maximum PTO Speed	540 rpm
Ram Bore Diameter	60 mm
Ram Stroke	400 mm
Ram Rod Diameter	40 mm
PTO Driven	Utilizes the tractor’s PTO for power
Splitting Force	10 tons
Axe Head	Forged, hardened, double chamfer for superior action
Mounting Options	Front or rear three-point linkage
Log Capacity	Logs up to 18 inches high; no width limitation
Safety Features	Anti-burst lagging on hydraulic pipes; requires both hands to operate
