Chapman Machinery FM150 ATV Flail Mower

Name: Chapman Machinery FM150 ATV Flail Mower
SKU: 9659
Price: 5200.00 GBP
Availability: InStock

£6,240.00 inc. VAT (£5,200.00 ex. VAT)

Chapman Machinery FM150 ATV Flail Mower

£6,240.00 inc. VAT (£5,200.00 ex. VAT)

Categories: Agricultural Machinery, ATV Machinery, Chapman ATV and UTV Machinery, Chapman Machinery

Chapman Machinery FM150 ATV Flail Mower

“EXCEPTIONALLY TOUGH & HEAVY DUTY”

Reliable Honda engine plus extremely robust build quality with fine attention to detail ensures these mowers withstand years of use

Product Description

Chapman Machinery FM150 ATV Flail Mower

Standard Specification:
– 1.5m Cut
– 21hp Honda V Twin
– Electric Start
– 22x11x8” Tyres
– Steel Y Flails
– Centrifugal Clutch

+BB	Breaker Bar to deflect vegetation such as reeds, rushes etc	£120 + VAT
+TA	Twin axle setup for rough terrain and reduced ground pressure	£600 + VAT
+CB	Cutter bar to increase mulching and decrease chop size	£120 + VAT
+JW	Jockey Wheel – recommended for wheels trailing	£80 + VAT

“EXCEPTIONALLY TOUGH & HEAVY DUTY”

Reliable Honda engine plus extremely robust build quality with fine attention to detail ensures these mowers withstand years of use

Designed for the full range of topping and mowing tasks, from thick dense rushes to fine topping of parkland, our range of Flail Mowers can tackle anything thrown at them.

Powerful 21hp Honda Petrol Engine
Heavy duty construction throughout
Unique double helix flail rotor
Large diameter tyres for smooth travel
Automatic belt tension system
Heavy duty ‘Y’ flails

POWER & PERFORMANCE

We use industry-leading 21hp Honda GX630 V-Twin Engines, which offer unparalleled power and performance. All machines are fitted with a heavy-duty rear roller to prevent scalping.

The compact design of the FM Series self-powered flail topper keeps the mass low to the ground for stability and allows cutting easily beneath trees and overhanging branches.

CLEAN & RELIABLE

The FM Series are fitted as standard with a centrifugal clutch, allowing for safe & efficient operation from the towing machine.

The centrifugal clutch gives automatic drive engagement and disengagement, and combined with the automatic tensioning assembly reduces maintenance by compensating for belt wear and belt loading.

UNIQUE ROTOR DESIGN

Our innovative rotor design incorporates a solid 40mm diameter drive shaft right through the centre of the rotor with a structural grade 90mm diameter outer tube, onto which the flail lugs are welded in a spiral pattern.

This unique design transfers cutting power more efficiently from the engine to the cutting heads, giving a cleaner cut and better performance in tough situations. Furthermore the rotor incorporates dedicated bearing guards designed to prevent string and wire damaging the bearings.

For further information, please contact our helpful team by clicking here.
